DIY: Back Wall Diffuser Array/Bass Trap

Getting more out of your back wall diffuser array with a simple hanging DIY array/bass trap.

One of the big “back wall” questions people have is “If I have a large diffuser array, how can I get the bass trapping I need?”  A great answer to this question is to turn the entire array into a hanging bass absorber.  If you are already planning on getting diffusion for your back wall, here is a great way to use that wall space for more than just diffusion.

Stuff you need:

bass trap foam diffuser -decon- front

Assembly instructionsbass trap foam diffuser - side

  • Screw the two IsoHangers to the plywood, using a fender washer on each screw. These should be about an inch in from each end -drill small pilot holes first. (These will be used to hang the panel, this side will be designated as the back from here on out.)
  • Use Construction adhesive to attach the Cutting Wedge® Foam to the back of the panel in a checkerboard pattern (each panel 90° rotated from adjacent)
  • Use Construction adhesive again to attach the 8 Diffusers to the front of the Plywood (Follow the installation instructions for adhesive placement)
  • Attach the Rings or Wire to the free end of the IsoHangers.

What you have created is a hanging panel that will diffuse mid-high frequencies and trap the lows.  The hanging mass absorbs low frequency energy by moving slightly when pushed by the energy of the Low frequency Waves.  The rear facing fiberglass also absorbs low frequencies by dampening the panel, but it also absorbs any of the waves that happen to get trapped behind the panel.

bass trap foam diffuser - rear

Hanging the Diffuser/Trap Assembly

  • Measure and attach the Closet Brackets to the Wall – Use appropriate anchors!  If you have standard or double wall construction without Resilient Channels, use the studs – The IsoHangers will keep vibrations from transmitting through the wall.
  • Hang the panel on the Closet Brackets using the rings/wire with the Diffusers facing you and that’s it!

bass trap foam diffuser - frontThis simple DIY project is provided as a way for our customers to learn better ways to use our products and get more value out of the products they buy.  For those customers who are planning on purchasing diffusers to make an array, or maybe already have an array and are looking to try a new configuration – this project may be what you’re looking for.

A little History…

If you embark on this little construction project, you will be constructing studio elements that have remained basically unchanged since at least the early 1970’s.  Hanging plywood wrapped in studio foam or fiberglass has been used “behind the curtains” of many of the top studios for effective bass control for over 40 years – just no one has ever seen it, as it has been hidden in walls; masked as a false wall of fabric stretched across wooden louvers!

————————————————————————————————————————————————————————————

Acoustics First Corporation supplies acoustical panels and soundproofing materials to control sound and eliminate noise in commercial, residential, government, and institutional applications worldwide.  Products include the patented Art Diffusor®, sound absorbers, noise barriers, acoustical fabrics and accessories. Acoustics First® products are sold for O.E.M applications, direct, and through dealers.  For more information on acoustical materials and their application, please visit www.AcousticsFirst.com or call Toll Free 1-888-765-2900 (US & Canada).

, , , , , , , , , , , , , , , , , , , , , ,

Leave a comment

DIY: How to quiet down that noisy equipment rack

rackDIY Project – Rack issues



Take a few seconds and DIY fix some of the common problems with using equipment racks!

Not too many people think about their equipment racks, but many of us use them.  Usually it’s something like what you see to the right – the great, sturdy, utilitarian box.  Unfortunately, there are a couple inherent problems with these:

  • Ringing – The metal resonates causing a ringing effect – may be masked by program material.
  • Reflections – many times your rack is near sound sources causing reflections off the hard surfaces.
  • Noise – Fans and other devices in the rack can make noises that are disruptive to recording.

Here are a few DIY fixes for these common problems.

  • Composite foam with adhesive backing is perfect for stopping the ringing of filler panels.
  • Use some Composite Foam to line your trays, drawers and shelves to keep items from rattling around inside the case.
  • Make a temporary cover for the front and back with BlockAid® sound barrier with minimal ventilation cut-outs to use during takes if rack-borne noise is problematic.

This simple DIY project is provided as a way for our customers to learn better ways to use our products and get more value out of the products they buy.  If you are looking for more ways to use the products you have, look to Acoustics First for Ideas.  http://www.acousticsfirst.com

————————————————————————————————————————————————————————————

Acoustics First Corporation supplies acoustical panels and soundproofing materials to control sound and eliminate noise in commercial, residential, government, and institutional applications worldwide.  Products include the patented Art Diffusor®, sound absorbers, noise barriers, acoustical fabrics and accessories. Acoustics First® products are sold for O.E.M applications, direct, and through dealers.  For more information on acoustical materials and their application, please visit www.AcousticsFirst.com or call Toll Free 1-888-765-2900 (US & Canada).

, , , , , ,

Leave a comment

DIY: How to build a Studio GoBo

DIY Project: Diffuser Array/Absorber GOBO

By: James DeGrandis

Mobile DIY option for creating new spaces with GOBOs!

As studio spaces get smaller, and budgets get tighter, we like to find new ways to maximize our budgets and our spaces, without removing quality. One issue with small room recording is getting sufficient separation between instruments – and here’s one DIY project to help you master your space without compromise.

Stuff you need:

4’x 6’ sheet of 3/4” Plywood (This can be scaled up or down depending on need.)

32 sq/ft of 4” Cutting Wedge® Classic Acoustical Foam (Or similar absorber)

4 x Art Diffusors® – Model C (or Model F, Quadrapyramid™, or other comparable diffuser)

Construction adhesive

6-8 Hook and loop straps (To attach to Mic Stands – one option)

2x Mic Stands (unless building frame)

2”x4”x10’ wood for frame construction (optional)

3 x Low profile Casters for rolling frame (optional)

DIY-gobo foam diffuser no frame decon front better

Assembly instructions

DIY-gobo foam diffuser no frame front strapsA simple “no-frame” construction method is first described to give you the quick and easy option of just attaching some straps to a couple mic stands.

Use Construction adhesive to attach the Cutting Wedge® Foam to the back of the panel in a checkerboard pattern (each panel 90° rotated from adjacent.) Then flip the panel and attach the 8 Cutting Wedge® panels to the bottom of the front. (the bottom of the gobo creates a corner with the floor, we want to put absorption there to limit the bass.)

Use Construction adhesive again to attach the 4 Diffusers to the top and front of the Plywood (Follow the installation instructions for adhesive placement)

If you with to attach to mic stands, just attach the hook and loop straps to the panel along the edge, roughly where the diagram to the right is indicating, and you are done…

If you would like to create a simple rolling frame, a design for one is shown in the bottom diagram on the right.  Other frame designs can be used; they can even be hung from the ceiling if you are going to keep reusing the same configuration, or if the configuration is going to be used long term.

One of the great benefits of building gobos is the flexibility you have in your use and placement of them.  They can allow for your space to seem much larger, by creating separation between instruments.  They are easily made, easy and quick to set up, they can be stored away, or just lean up against a wall or corner to provide more acoustic treatment when not in use.

DIY-gobo foam diffuser -new standCreate a mini vocal booth.

Use as a giant corner bass trap.

Enclose your noisy drummer.

Gobos have hundreds of uses.

Make your own today!

This simple DIY project is provided as a way for our customers to learn better ways to use our products and get more value out of the products they buy.  If you are looking for more ways to use the products you have, look to Acoustics First for Ideas.  http://www.acousticsfirst.com

A little History…

If you embark on this little construction project, you will be constructing studio elements that have remained basically unchanged since at least the early 1970’s.  Handmade Gobos have been used in many of the top studios for effective noise control for over 40 years – These versions pay homage to those early pioneers who built what they needed, because it was the only way to get exactly what they needed.

DIY-gobo foam diffuser no frame front

————————————————————————————————————————————————————————————

Acoustics First Corporation supplies acoustical panels and soundproofing materials to control sound and eliminate noise in commercial, residential, government, and institutional applications worldwide.  Products include the patented Art Diffusor®, sound absorbers, noise barriers, acoustical fabrics and accessories. Acoustics First® products are sold for O.E.M applications, direct, and through dealers.  For more information on acoustical materials and their application, please visit www.AcousticsFirst.com or call Toll Free 1-888-765-2900 (US & Canada).

, , , , , , ,

Leave a comment

Acoustic First Ceiling Tiles get a face lift for the perfect fit to any application

For Immediate Release

Acoustic First Ceiling Tiles get a face lift for the perfect fit to any application.

Acoustics First® has expanded their line of acoustical ceiling tiles allowing you to dress up any ceiling grid with a generous number of finish options.  The legacy line of Sonora® ceiling tiles includes fabric faced ceiling tiles in either the standard square edge or a tegular edge that reveals below the grid.  These tiles are available in a multitude of fabric colors and can be utilized in a wide range of applications to provide an upscale ceiling system that looks as good as it sounds.  If you are looking for the absence of color, there are now two white options.  The Sonora® UltraWHITE facing provides a basic smooth white finish while the  Sonora® Nubby tile provides a texture white appearance.  White ceiling tiles are an excellent choice for areas where a seamless look is desired and maintaining a room that is both bright and vibrant.  Alternatively, if your application requires the ceiling to disappear, a black scrim version is also available.  These black scrim ceiling tiles are a popular choice for public theaters, home theaters, restaurants or any application where a dark ceiling is desired.  Additionally, choose from either a PVC faced or encapsulated ceiling tile if your application requires a wipe-able surface for resistance to liquids and dirt.  Test labs, animal shelters, restaurants and similar facilities may require their ceiling tiles to be cleaned on a regular basis. In addition the ample amount of absorptive ceiling tiles, Acoustics First® also carries a wide range of diffusive ceiling tiles including the patented Art Diffusor® Model C and Model F.  Product information, specifications and pricing can be found on the website @ http://www.acousticsfirst.com/sonora-ceiling-tiles.htm.

Image Downloads: http://www.mediafire.com/?21id1fsb0btrq
www.AcousticsFirst.com
Acoustics First Corporation

————————————————————————————————————————————————————————————

Acoustics First Corporation supplies acoustical panels and soundproofing materials to control sound and eliminate noise in commercial, residential, government, and institutional applications worldwide.  Products include the patented Art Diffusor®, sound absorbers, noise barriers, acoustical fabrics and accessories. Acoustics First® products are sold for O.E.M applications, direct, and through dealers.  For more information on acoustical materials and their application, please visit www.AcousticsFirst.com or call Toll Free 1-888-765-2900 (US & Canada).

, , , , , , , , , ,

Leave a comment

Model E Art Diffusors seen in Oddities East/West Marathon Trailer

If you watch closely, you will see the Acoustics First Model E Art Diffusor behind Khalil Ismael in the studio.

Seen @ 2 sec | 7 sec | 10 sec

Oddities East/West Marathon from Tyler Korba on Vimeo.

http://vimeo.com/45943583

Video Credit goes to:
VP Creative – Dan Bragg
Creative Director – Tom King
Writer/Producer – Tyler Korba Eye Candy DC
Creative Director – Heather Roymans
Editor – Justin Kanner
GFX – Andy Hsu Clean Cuts
Vocals – Khalil Ismael
Sound Design/Mix – Cadell Cook

For more information on diffusers, please visit:  http://www.acousticsfirst.com/diffusers-diffusors.htm

, , , , , , , , ,
